Schlage F58PLY613 Entrance Handlesets, Oil-Rubbed Bronze
Schlage F58PLY613 Entrance Handlesets, Oil-Rubbed Bronze
$109.36
SKU: 11851440
MFG: F58PLY613
Description
Highlights:
- Series: Plymouth F58
- Backset: 2-3/8" - 2-3/4"
- Strike: 2-1/4" X 1-5/8"
- Crossbore Size: 2-1/8"
- Finish : Oil rubbed bronze
- Metal construction adds strength, security and durability
- Dual Option Universal Latchbolt
- Exterior Handleset Only
- For residential single and multi-family entrance doors
- Deadbolt thrown or retracted by key from outside or by inside turn unit
- Latch retracted by thumbpiece from inside or outside grip
- Solid forged brass outside trim, wrought brass trim rings with concealed security inserts
- Wrought brass inside trim
- Wrought brass cylinder trim rings reinforced by tapered die cast security insert for resistance to wrenching or prying
- DOOR PREP: 1-1/2" or 2-1/8" deadbolt and 2-1/8" latchbolt Crossbore; 7/8" or 1" Edge Bore; 1" x 2-1/4" Latch Faces; 4" CTC
- DOOR THICKNESS: 1-5/8" to 1-3/4"; packed with extra mounting screws to accommodate 2" doors
- CYLINDER: 5-pin with nickel silver pins and keys (2)
- FACEPLATES: 1" x 2-1/4". STRIKES: Deadbolt - 1-1/8" x 2-3/4", square corner, no lip, dust box and door frame reinforcer
- BOLT: Maximum Security B300 single cylinder or B362 double cylinder deadbolt with 7/8" housing diameter, 1" throw
- ANSI/BHMA: Grade 1 Security features
- DUAL OPTION UNIVERSAL: Both handleset and deadbolt fit all doors, square corner, round corner, or drive-in preps
Specifications
MFR:
F58PLY613
SKU:
11851440
UPC:
043156164240
Brand:
Schlage
Length:
11
Width:
6
Height:
11
Attachment:
